The lvdt displacement Sensorr 4000TD on the steam turbine is usually used to measure the displacement of key components to monitor the operating status of the steam turbine and achieve control over it. Common turbine displacement sensor applications include:

1. Turbine bearing displacement sensor: measures the radial and axial displacement of the turbine rotor bearing to monitor the vibration of the rotor and prevent mechanical fatigue, damage, and other issues caused by vibration.

2. Steam turbine rotor displacement sensor: measures the radial and axial displacement of the steam turbine rotor to monitor the vibration and eccentricity of the rotor, and prevent faults such as rotor collision and jamming.

3. Steam turbine blade displacement sensor: measures the displacement and deformation of steam turbine blades to monitor their fatigue damage and deformation, early warning the risk of blade failure, and ensuring the safe operation of the steam turbine.

4. Turbine control valve displacement sensor: measures the opening and closing status of the turbine control valve to control the operating speed, load, and temperature parameters of the turbine.

These displacement sensors are generally installed in key parts of the steam turbine, such as bearing brackets, blade roots, regulating valve pistons, etc., to ensure accurate measurement and monitoring of measured displacement changes.
