Q641F-16C pneumatic flange ball valve is an industrial valve powered by compressed air and driven by a piston actuator to rotate the ball 90 ° for rapid opening and closing. The valve body is made of WCB cast steel through one-time molding, with a nominal pressure of PN16 and a suitable temperature of -29~180 ℃. It can operate stably in water, steam, oil and some weak acid and alkali media. Its floating ball design keeps the channel consistent with the pipe diameter, allowing the medium to pass through with almost no pressure loss, and the flow resistance coefficient is much lower than that of similar gate valves and globe valves. The valve seat is made of PTFE soft sealing material, combined with elastic compensation structure, which can achieve zero leakage under 1.6 MPa working condition; At the same time, the top of the actuator is equipped with an ISO 5211 standard platform, which can be easily installed with solenoid valves, limit switches, or electrical locators to achieve DCS remote control, local manual switching, and precise adjustment of 4-20 mA.

The product is compact in size and lightweight, with an overall weight of less than 10 kg for specifications below DN50, and requires low installation and maintenance space; The valve stem adopts an anti blow T-shaped structure and is equipped with anti-static springs and fire-resistant graphite packing, meeting the requirements of explosion prevention, fire prevention, and anti-static in the petrochemical industry. In petroleum refining facilities, it is often installed on atmospheric and vacuum distillation and catalytic cracking pipelines to quickly cut off crude oil, oil and gas, or steam; In the field of chemical engineering, it can be installed at the inlet and outlet of reaction vessels to achieve safe isolation of corrosive solvents; The boiler feedwater system of the power plant utilizes its 0.5-second fast closing characteristic to quickly cut off the steam source when the steam drum water level is abnormal, preventing water hammer accidents.

Due to the optional double acting or single acting (spring reset) of the actuator, Q641F-16C is suitable for continuous adjustment conditions and can also be used as an emergency shut-off valve; Combined with the handwheel mechanism, it can be manually operated even in the event of a gas source interruption, ensuring system safety. The coverage range from DN15 to DN600, multiple pressure levels from PN16 to PN63, and multiple material configurations such as WCB, CF8, CF8M make this valve a universal and reliable key equipment in automation pipelines in industries such as petroleum, chemical, metallurgical, pharmaceutical, papermaking, and refrigeration.
