HSNSQ3440-46 Three-screw pump mechanical seal made in China
Date:2023/3/16 9:24:36 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,HSNSQ3440-46 Three-screw pump mechanical seal made in China
The Three-screw pump mechanical seal HSNSQ3440-46 is an important component of the oil pump HSNSQ3440-46. The radial rotation runout of the main rod of the three-screw pump is positioned by the balance piston sleeve, which can also be called a sliding bearing, and the high-pressure chamber is made by means of the gap between the balance piston and the shaft sleeve. It is separated from the sealing chamber, and a mechanical seal is installed in the sealing chamber without leakage. The oil return hole in the chamber communicates with the suction chamber of the pump, so it is not affected by the discharge pressure.
Three-screw pump HSNSQ3440-46 is a side-inlet and side-outlet vertical oil pump, which is suitable for sealing oil control system. There are two main AC oil pumps in this device, one is working and the other is standby. They are all driven by AC motors, so they are also called AC oil pumps. This pump is put into operation when the main oil pump fails.
When three-screw pump HSNSQ3440-46is running in a dusty environment, in order to improve the cooling effect and prevent spontaneous combustion, the surface of the pump and motor should be cleaned regularly according to the degree of dust accumulation.
GV1 quick-close solenoid valve 12YV
GV2 quick-close solenoid valve 13YV
GV3 quick-close solenoid valve 14YV
GV4 quick-close solenoid valve 15YV
ICV1 quick-close solenoid valve 16YV
ICV2 quick-close solenoid valve 17YV
RSV2 trip solenoid valve 18YV
RSV1 trip solenoid valve 19YV
OPC solenoid valve 4WE6D62/EG220N9K4/V
OPC solenoid valve R901008688
shutdown electromagnet CN70093-01
oil three-screw pump HSND280-46N
servo controller BGCD-6121B
DC Emergency pump 70LY-45
temperature Regulating valve LWH-ZG1/2
Regulating valve diaphragm 250ZXNOCEQ12SNOERH
actuator diaphragm KS250ZXNO16BQ12SNOERH
servo valve SM4-40 (40)151-80/40-10-S205
servo valve SM4-20 (15)57-80/40-10-S182
servo valve S63J0GA4VPL
DFYLSYC-2023-03-16-A
mechanical,three-screw,Pump,seal
