Direction for use

Pyopress pressure switch P530 series has unique switch box adsorption from PPS engineering polymer injection molding.



Technical parameters of PS531SPP10/BB32N3/S3M:

1. Stainless steel or black anodized aluminum enclosure, grade IP67.

2. The integral junction box is electrically connected through M20.

3. Closed circuit monitoring resistor option.

4. The applicability of SIL 2 IEC 61508 has been verified and documented.
