Sealing Oil System
Date:2016-7-12 20:34:07 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,China Sealing Oil System Pump Valve Manufacturer
PRODUCT DESCRIPTION
Sealing oil system of generators provides sealing oil with pressure slightly higher than hydrogen pressure for the sealing bearings, to avoid hydrogen inside the generator leaking from where the shaft extends. After getting into the sealing bearing, the sealing oil goes through the gap between bearing and shaft, outflows from two sides of the shaft (produces hydrogen-side oil return and gas-side oil return), then forms a sealing recalculate at the gap to prevent the hydrogen from leaking.
The sealing oil system mainly includes: normal operation circuit, accident operation circuit, emergency sealing oil circuit (the third sealing oil source), vacuum device, pressure regulating device, and switches. These circuits and devices can complete the automatic adjustment, signal output, and alarm functions of the sealing oil system
Main equipments of 300MW, 600MW and 1000MW Generators sealing oil system:
· Sealing Oil Pump
· Differential Pressure Valve
· Sealing Oil Filter
· DN80 Floating Ball Valve for Vacuum Tank
· DN40 Floating Ball Valve for Vacuum Tank
· Vacuum Pump 30-WS
· Circulating Pump HSND280-46N
· Seal Oil Enlargement Slot
· Air Extract Slot
REGULAR SPARES
Sealing Oil Pump | Differential Pressure Regulating Valve |
Sealing Oil Filter | Vacuum Oil Purifier Device (Vacuum Tank, Vacuum Pump and Circulating Pump) |
Float Tank | Sealing Oil Enlargement Slot |
Air Extract Slot | Sealing Ring |
AVAILABLE MODELS
Sealing Oil Filters:
![]() |
Sealing Oil Filter |
Sealing Oil Pump Outlet Filter MKW28AT001 | |
Pumps for Sealing Oil System:
![]() |
Sealing Oil Pump HSND280-46N |
Sealing Oil Pump HSNH80Q-46NZ | |
Sealing Oil Pump HSNH440Q2-46NZ | |
Sealing Oil Pump ACG070K7NVBP | |
Sealing Oil Vacuum Pump 30-WS | |
Sealing Oil Vacuum Pump KZ/100WS | |
Vacuum Pump Reducer M02225.OBMCC101.5A | |
Vacuum Pump Mechanical Seal P-2811 |
Valves for Sealing Oil System:
![]() |
Sealing Oil Relief Valve 98H-109 |
Sealing Oil Tank Ball Float Valve DN80 | |
Sealing Oil Tank Ball Float Valve DN40 | |
Ball Float Valve FY-40 | |
Ball Float Valve 1A173 | |
Ball Float Valve 1A3246 | |
Ball Float Valve 1A424 | |
Ball Float Valve PY-40 | |
Ball Float Valve BYF-80 | |
Sealing Oil Differential Valve 977HP |
Other Components for Sealing Oil System:
Oil Water Alarm OWK-2
Recommended Products
![]() |
![]() |
![]() |
![]() |
Valves for Hydrogen Cooling System | Generator Cooler | DF6101 Series Rotational Speed Sensor | Wear Resistant Ceramic Lined Steel Pipe |
Please contact us if your need is not listed above. SEND EMAIL
