TDZ-1-02 China factory hydraulic motor LVDT Position displacement Sensor

Date:2023/6/20 10:16:03 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

 TDZ-1-02 China factory hydraulic motor LVDT Position displacement Sensor


LVDT Position displacement Sensor TDZ-1-02 is suitable for monitoring and protecting the stroke and valve position of hydraulic motors. The LVDT displacement sensor has good dynamic characteristics and can be used for high-speed online detection; The LVDT displacement sensor has a simple structure, small volume, reliable operation, convenient use and maintenance, and long service life; Good nonlinearity and high repeatability accuracy. Widely used in various fields, suitable for industries such as power plants and steel mills.
The LVDT Position displacement Sensor TDZ-1-02, also known as a linear sensor, is a linear device that belongs to metal induction. Its function is to convert various measured physical quantities into electrical quantities. During installation and use, the alignment of the linear displacement sensor should be strictly ensured. If the alignment deviation and tilt deviation of the sensor exceed the required tilt angle during installation and use of the product, the detection results will be greatly affected. When users choose to use displacement sensors, they should strictly follow the manufacturer's guidance documents to install, use, or maintain the product to avoid affecting the detection accuracy of the sensor.

technical parameter of LVDT Position displacement Sensor TDZ-1-02
1. Linearity: ± 0.3% of full stroke.
2. Working temperature: -40~150 íŠ (conventional) -40~210 íŠ (high temperature)
3. Sensitivity coefficient: ± 0.03% FSO./íŠ
4. Leads: Three polytetrafluoroethylene insulated sheathed cables, external stainless steel sheathed hoses.
5. Vibration tolerance: 20g to 2 kHz.
