China OEM Speed trancducer for Turbine SMCB-01-16L Magnetic sensitive speed sensor

Date:2023/6/8 10:55:24 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

 China OEM Speed trancducer for Turbine SMCB-01-16L Magnetic sensitive speed sensor

The SMCB-01-16L Magnetic sensitive speed sensor adopts a new type of SMR sensing element, triggered by a steel magnet, with wide frequency response (from static to 30KHZ), good stability, and strong anti-interference characteristics; There is an amplification and shaping circuit inside, which outputs a stable square wave signal and can achieve long-distance transmission. It can measure rotational speed, displacement, angular displacement, and accurately locate related equipment. The product has high reliability and is sturdy and durable.
technical parameter of SMCB-01-16L Magnetic sensitive speed sensor
Working voltage: DC12V or (11-13) V
Response frequency: 0.3Hz~1KHZ or 1HZ~20KHZ
Output signal: single channel: square wave signal. Rongping: approximate power supply voltage; Low level: voltage; Low level: ≤ 0.7V.
Trigger form: steel gears, racks, or other soft and hard magnetic materials
Tooth width distance: ≥ 1.5mm
Working distance: (0-2.5) mm
Operating temperature: -25 ° C~+80 ° C
Applicable humidity: ≤ 95% RH
Measurement accuracy:+1 pulse
Protection form: polarity, short circuit
Protection level: IP65
Output method: TTL, NPN, or PNP type. Default PNP output
Weight: approximately 195g
