The WTYY-1021 industry Remote bimetallic thermometer not only meets the needs of on-site temperature measurement but also long-distance transmission. The remote transmission bimetallic thermometer can directly measure the temperature of liquid, vapor, gas medium, and solid surface in the range of -40~+600 ℃ in various production processes.



Performance of industry Remote bimetallic thermometer WTYY-1021

1. It has the characteristics of small temperature measurement probe, high sensitivity, linear scale, and long service life.

2. It has multiple functions such as remote output resistance signal (PT100), seismic resistance, corrosion resistance, and high-power switching signal.

3. Various sizes can meet the needs of various industrial environments.



Main technical parameters of industry Remote bimetallic thermometer WTYY-1021:

1. Temperature measurement range -40~600 ℃

2. Environmental temperature -10~55 ℃

3. Relative humidity ≤ 95%

4. Accuracy level 1.5

5. Time constant ≤ 60S

6. Probe pressure resistance ≤ 6Mpa

7. Probe diameter: φ 8-10mm, movable external thread: M27 * 2

8. Thermal resistance PT100 (single or dual output) or 4-20mA current output

9. Protection level: IP55
