The steam turbine LVDT Position Sensor HL-3-300-15 belongs to the HL-3 series of sensors and adopts the working principle of a movable differential transformer with an iron core. This working principle is based on the characteristics of a differential transformer. The sensor changes the inductance value through the displacement of the movable iron core, generating an electrical signal output proportional to the displacement, achieving automatic monitoring and control of displacement.

These two sensors have a series of superior features. Firstly, they have excellent dynamic characteristics and can quickly respond to displacement changes. This makes them very suitable for high-speed online detection and can accurately monitor and control the displacement changes of the measured object in real-time.

Secondly, the steam turbine LVDT Position Sensor HL-3-300-15 has a simple structure and compact size, which makes installation and integration more convenient and efficient, while its compact size makes it suitable for various limited space application scenarios. These sensors can be easily installed and used both inside compact devices and in limited installation space. The operational reliability of these two sensors is also one of their significant characteristics. They have undergone strict quality control and reliability testing, possessing excellent anti-interference ability and stability. Whether in harsh working environments or long-term use, these sensors can continue to work reliably, ensuring accurate displacement measurement and reliable control. In addition, the  LVDT Position Sensor HL-3-300-15 does not have excellent nonlinearity and repetitive accuracy. Good non linearity means that the output of the sensor has a good relationship with displacement, providing accurate and reliable measurement results. High repetition accuracy indicates that under the same displacement conditions, there is a small error between multiple measurement results, ensuring the consistency and reliability of the measurement results. In summary, the steam turbine LVDT Position Sensor HL-3-300-15 is based on the working principle of differential transformer, and has the advantages of good dynamic characteristics, simple structure, small size, reliable operation, convenient use and maintenance, long service life, good nonlinearity, and high repetition accuracy. These characteristics make them widely used in various industrial applications.
