The Oil pump outlet dual cylinder high-pressure filter SGF-H110*10FC is installed on the high-pressure pipeline at the oil pump outlet to protect the control components and actuator. Especially in automatic control systems, high-precision servo components and plunger components can effectively prevent pollution, avoid faults, and extend the service life of the components.



The filter is installed on the high-pressure pipeline at the oil pump outlet to protect the control components and actuator. Especially in automatic control systems, high-precision servo components and plunger components can effectively prevent pollution, avoid faults, and extend the service life of the components.





This Oil pump outlet dual cylinder high-pressure filter SGF-H110*10FC is composed of two single cylinder filters, a directional valve, a bypass valve, a transmitter, etc. It can enable the system to replace the filter element without stopping the machine, and is used in continuous hydraulic systems.





When the filter element of one of the filters is blocked until the pressure indication value of the differential pressure transmitter is 0.5MPa, the transmitter sends a signal and the filter element must be replaced. As long as the directional valve and the other backup filter are turned, they will immediately work. At this point, all you need to do is release the plug and drain the oil, and then unscrew the housing to replace the clogged filter element. The filter cartridge on the filter element side needs to be replaced to allow for a small amount of internal leakage.



If for some reason the filter element cannot be replaced in a timely manner, and the pressure difference continues to rise to the opening pressure of the bypass valve to 0.6MPa, the bypass valve will automatically open to avoid further contamination caused by the rupture of the filter element due to the continued increase in pressure. However, users must replace the filter element when the transmitter sends a message.
