25FJ-1.6PA2 Steam turbine stainless steel globe valve flange made in China
Date:2023/5/18 14:37:38 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,25FJ-1.6PA2 Steam turbine stainless steel globe valve flange made in China
When the shut-off valve is opened, the opening height of the valve disc is 25% to 30% of the nominal diameter, and the flow rate has reached its maximum, indicating that the valve has reached the fully open position. So the fully open position of the shut-off valve should be determined by the stroke of the valve disc. This type of valve should generally be installed horizontally in pipelines.
advantage of 25FJ-1.6PA2 Steam turbine stainless steel globe valve flange
1. The structure is simple, and manufacturing and maintenance are relatively convenient.
2. Small working stroke and short opening and closing time.
3. Good sealing performance, low friction between sealing surfaces, and long service life.
The disadvantages of shut-off valves are as follows:
1. The fluid resistance is high, and the force required for opening and closing is high.
2. Not suitable for media with particles, high viscosity, and easy coking.
3. Poor regulation performance.
The structural form of the 25FJ-1.6PA2 Steam turbine stainless steel globe valve flange:
The straight through structure of the globe valve body is the most common, but its fluid resistance is the highest. Direct flow fluids have low resistance and are often used for fluids containing solid particles or with high viscosity. The right angle valve body is mostly forged, suitable for globe valves with smaller diameter and higher pressure.
