Displacement sensor LVDT 3000TD-E range 0-150mm
Date:2022/10/29 9:56:14 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,Displacement sensor LVDT 3000TD-E range 0-150mm
The Displacement sensor LVDT 3000TD-E converts the mechanical measurement of linear motion into electrical energy. Through this principle, the sensor can automatically measure and control the displacement. The sensor has the advantages of simple structure, high reliability, good use and maintenance, long service life, good linearity and high repeatability. It has a wide measurement range, low time constant and fast dynamic response.
Precautions of Displacement sensor LVDT 3000TD-E
1. Sensor wires: primary: brownish yellow, sec1: black-green, sec2: blue-red.
2. Linear range: within the two tick marks on the sensor stem (based on "entry").
3. The sensor rod number and housing number must be the same to support the use.
4. Sensor fault diagnosis: measure PRI coil resistance and SEC coil resistance.
5. Keep the sensor housing and the signal demodulation unit away from strong magnetic fields.
