LVDT displacement sensor 6000TD, with a range of 0~300mm, is applicable to the monitoring and protection of hydraulic servo-motor travel and valve position. The LVDT displacement sensor 6000TD has good dynamic characteristics and can be used for high-speed online detection.

The LVDT displacement sensor 6000TD has simple structure, small volume, reliable operation, convenient use and maintenance, and long service life; Good nonlinearity and high repeatability.



Technical parameters of LVDT displacement  sensor 6000TD

1. Linear range: 0~300mm.

2. Linearity: ± 0.3% of full stroke.

3. Working temperature: - 40~150 ℃ (normal) FSO/ ℃

5. Lead wire: six Teflon insulated sheathed cables, external stainless steel sheathed hoses.

6. Vibration tolerance: 20g to 2 kHz.
