YOYIK in stock jacking oil system back-flushing filter ZCL-I-450

Date:2020-2-10 9:37:30 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

The jacking oil system back-flushing filter ZCL-I-450 is widely used in the turbine oil system and the auxiliary machine lubrication system. In addition, the device is used as a temporary filtering device for the steam cycle of the steam turbine unit, which can also improve the quality of the oil system flushing and shorten the oil circulation time.

Structure:

The automatic back-flushing oil filter is composed of a cylinder body and a filter element. The filter element is composed of a top cover assembly, a sewage discharge mechanism, a filter core, a cover assembly, a base assembly and the like, and is vertically placed in the cylinder body.

Working conditions

1. System Fluid: Turbine Oil

2, system temperature: 15 °C-70 °C

Technical Parameters

1, rated flow: 450 L / min, 250 L / min

2. Working pressure: 0.6 MPa

3. Pressure loss: ≤0.025 MPa

4. Sewage frequency: 50 times / min - 100 times / min

Pls feel free to contact us if you need any other filters:

regeneration device anion filter/regenerating filter/anion filter

regeneration device cation filter/regenerating filter/cation filter

EH oil main pump discharge filter (working)/EH pump filter/pump discharge filter/EH pump working filter

EH oil main pump discharge filter (flushing)/EH pump filter/pump discharge filter/EH pump flushing filter

oil-return filter (working)/return oil filter/EH oil return filter/circulating pump oil filter

oil-return filter (flushing)/return oil filter/EH oil return filter/circulating pump oil filter

regeneration device diatomite filter/regenerating filter/diatomite filter

regeneration device Precision filter/regenerating filter/Precision filter

actuator inlet filter (flushing)/actuator filter/actuator flushing filter

actuator inlet filter (working)/actuator filter/actuator working filter

actuator filter (flushing)/actuator flusing filter/HPCV actuator filter
