DYK-11-1013 guide vane opening instrument 50HZ AC220V 4~20mA

Date:2017/12/20 17:20:07 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

DYK-11-1013 guide vane opening instrument 50HZ AC220V 4~20mA

DYK-11-1013 guide vane opening instrument is a series of products with high accuracy and applicability developed for the measurement of guide vane opening, gate opening, servomotor travel and shaft angle of hydropower station. The instrument collects transmitter signals, can display displacement travel and opening percentage, can set eight alarm outputs at will, and has analog output.

 Technical parameters of  DYK-11-1013 guide vane opening instrument

Measuring signal: displacement sensor signal form: current 4~20mA

Measurement accuracy: nonlinearity 0.3%

Contents of digital display: displacement stroke value, opening percentage, output setting value of each circuit.

Switching value output signal: 8 channels, each point can be set by the user within the specified range.

Output contact capacity: 5A/250VAC, 5A/30VDC

 Analog output: 4~20mA

 Working environment: temperature 0~50c, humidity<85%

Working mode: continuous

Power supply: 110V/220VDC or AC110/220V/50Hz

Power consumption: 10W
