The HDGCX40 liquid level transmitter is a high-precision and high-performance liquid level measurement device widely used in industrial, chemical, petroleum, water treatment and other fields. This device adopts advanced pressure sensing technology, which can accurately measure the height or pressure of liquids and convert the signals into standard electrical signals for remote monitoring and automation control.

FEATURES

1. Measurement range and accuracy

HDGCX40 can meet most liquid level measurement needs. Its high-precision design ensures the reliability of measurement results and is suitable for scenarios with high requirements for liquid level changes.

2. Adaptability to work environment

The working temperature range of this liquid level transmitter is -10 ℃ to 80 ℃, and it can operate stably within a wide temperature range. Its shell is made of stainless steel material, which has good corrosion resistance and waterproof performance, with a protection level of IP68, suitable for long-term use in harsh environments.

3. Output signal and power supply

HDGCX40 supports 4-20mA standard current signal output and is compatible with various industrial control systems. Its power supply voltage is 24VDC, which meets the common power configuration in industrial sites and is very easy to install and use.
