The  Original turbine EH oil tank air filter element BR110 is applicable to the EH oil tank of the turbine. The air filter element is located on the oil tank and is the "mask" of the oil tank. It has the function of preventing pollutants from mixing with air into the oil tank due to changes in oil volume. Therefore, the filter element selected for this filter should have the same performance requirements as other hydraulic filter elements to prevent Cavitation caused by the negative pressure in the oil tank due to micropore blockage. Pay special attention to the protection of the air filter element in outdoor environments and when the surrounding environment is harsh. Usage: Insert the lower part directly into the fuel tank, with a small hole on the bottom end face of the upper cover, which is the air inlet, and the part inserted into the fuel tank is the filter layer. Effectively dehumidifying and preventing water and particles from entering the EH fuel tank, providing protection for the system, effectively reducing operating costs and improving system performance.



Air filtration is suitable for the EH oil tank of steam turbines, effectively dehumidifying and preventing water and particles from entering the EH oil tank, providing protection for the system, effectively reducing operating costs and improving system performance. It must be used in conjunction with the BR110 air filter to effectively improve the service life of the air filter.
