The six wire linear LVDT displacement sensor 1000TD belongs to the six wire system sensor, and its working principle is a movable transformer with an iron core. The sensor consists of three sets of coils, one primary coil, and the outgoing wires are brown and yellow; There are two sets of secondary coils, one with black and green outgoing wires, and the other with blue and red outgoing wires. LVDT displacement sensor 1000TD, also known as differential transformer type displacement sensor, connects the green and blue lines as differential outputs.



The six wire linear LVDT displacement sensor 1000TD is a sensor used to measure the relative position or position change of an object. It can convert the displacement information of the measured object into electrical signals or other forms of signal output. Displacement sensors are widely used in various measurement, monitoring, and control systems, and have the following functions:

1. Position detection: capable of detecting the position information of objects and determining their position by outputting electrical signals or other signals.

2. Motion control: It can measure the position changes of objects, thereby helping the control system achieve precise motion control.

3. Quality inspection: It can detect the deformation and displacement of objects, which can be used to judge the quality and stability of objects.

4. Strain analysis: it can measure the small deformation of objects, so that strain analysis and Structural health monitoring can be carried out.

5. Automation control: It can be used in conjunction with computers and other automation control equipment to achieve automation control and data collection.
