The Steam turbine stainless steel  LVDT Displacement sensor 3000TD  converts mechanical measurements of linear motion into electrical energy. Through this principle, sensors can automatically measure and control displacement. The sensor has a simple structure, high reliability, good usability and maintenance, long service life, good linearity, and high repeatability accuracy. It has a wide measurement range, low time constant, and fast dynamic response.

Precautions for using  Steam turbine stainless steel  LVDT Displacement sensor 3000TD:

1. Sensor wire: primary: brownish yellow, sec1: black green, sec2: blue red.

2. Linear range: Within the two scale lines of the sensor rod (based on "inlet").

3. The sensor rod number and housing number must be consistent to support use.

4. Sensor fault diagnosis: Measure the resistance of PRI coil and SEC coil.

5. Keep the sensor housing and signal demodulation unit away from strong magnetic fields.
