HY-5V ntelligent Module Vibration monitoring and protection device can monitor the vibration intensity of rotating machinery for a long time, and can monitor the vertical and horizontal vibrations of rotating machinery. The vibration intensity value is displayed by the meter head on the front panel of the instrument, and has a standard current output. It can be connected to various DCS and PLC systems. When the vibration value exceeds the limit, the instrument can be externally connected with an audible and visual alarm to remind on-site operators to take preventive measures, and there is a report Dangerous switch output ensures safe and reliable operation of the machine.

TheHY-5V ntelligent Module Vibration monitoring and protection device protects the vibration of the bearing shells of rotating machinery such as steam turbines, water turbines, compressors, and blowers. Mainly suitable for fields such as power generation, steel, metallurgy, chemical engineering, etc., continuous monitoring and measurement of bearing vibration (absolute vibration) and shaft vibration (relative vibration) of various types of rotating machinery. In this type of machine, shaft vibration can be transmitted to the casing more frequently. Therefore, this monitor can be equipped with a magnetoelectric speed sensor for continuous measurement and protection of rotating machinery. Special attention should be paid to the installation of the sensor to avoid reducing the amplitude of the sensor, And the frequency influence is changed or the generated signal cannot represent the true vibration of the machine. For motors, compressors, fans, and other situations where a large number of vibration points need to be measured, it is convenient for users to analyze and maintain the working condition of the machine. Equipped with current output, it can be used for connecting external recorders and microcomputers.
