The steam turbine rotation speed sensor SZCB-01-A1-B1-C3 is a sensor for measuring the speed of rotating machinery, and its working principle is based on the reluctance effect. The sensor consists of a magnetic ring, a reluctance rod and a coil.

When a rotor such as a gear on the magnetic ring rotates around it, due to the existence of the gear, the magnetic flux between the reluctance rod and the magnetic ring changes periodically with the rotation, resulting in changes in the reluctance values at both ends of the reluctance rod. This changing signal is sent to the coil, and the voltage pulses generated by the coil indicate the rotational speed.



Because the working principle of the steam turbine rotation speed sensor SZCB-01-A1-B1-C3 is relatively simple, the structure is compact, the precision is high, and the reliability is strong, it is widely used in the speed of various rotating machines such as steam turbines, generators, and compressors. measuring.
