The  installation method of WZPK2-16A platinum thermal resistance rtd temperature sensor needs to be determined according to the specific application. The following are some common installation methods:

Direct insertion method: Insert the platinum thermal resistance temperature sensor directly into the measured medium, which is suitable for occasions where the medium is liquid or gas.

Pipe installation method: install the platinum thermal resistance temperature sensor in the pipeline, and measure the temperature of the medium through the conduction of the medium in the pipeline.

Intrusive installation method: Install the platinum thermal resistance temperature sensor in the measured medium, which is suitable for occasions where the medium is solid.

Surface mount method: The platinum thermal resistance temperature sensor is directly attached to the surface of the measured object, which is suitable for occasions where the surface temperature of the measured object changes little.

When installing WZPK2-16A platinum thermal resistance rtd temperature sensor, care must be taken to protect the cable of the sensor to avoid cable damage or interference. In addition, the sensor should be as close to the measured medium as possible to improve the measurement accuracy.
