Speed rotation sensor SZMB-4 by yoyik

Date:2020/9/2 15:11:51 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

 Speed rotation sensor SZMB-4 rconverts the angular displacement into electric pulse signal for counter use. The sensor is composed of induction gear, induction tooth base, induction coil, magnetic steel, etc. When there is relative angular displacement between the induction gear and the induction gear seat, the induced electromotive force is generated in the induction coil due to the change of the magnetic resistance in the magnetic circuit. After amplification and shaping, the square wave signal of electric pulse is output.

 Speed rotation sensor SZMB-4 by yoyik
