BFP lube filter QF9732W50HPTC-DQ yoyik supplyDate:2020-8-31 10:12:04 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,
The lubricating oil system has a filter screen type oil filter, which is installed at the bottom of the oil return tank in the oil tank. The filter screen is cylindrical, which is composed of filter screen and metal grid with holes. It is embedded in the opening cut at the bottom of the tank. The return oil flows through the oil filter by gravity, and flows into the oil tank from the side and bottom of the oil filter. There is a handle on the top of the oil filter. During maintenance, the filter screen can be taken out through the inspection port for cleaning or replacement. However, it is not allowed to pull out the filter screen during the operation of the unit.
The lubricating oil system is mainly composed of main oil pump, oil cooler, oil injector, jacking oil system, smoke exhaust system, main oil tank of container oil tank), replacement of lubricating oil pump with oil pump, standby sealing oil pump, filter screen, electric heater, valve, check valve and various monitoring instruments.
oil filter ZL-160*80
EH oil main pump suction filter OF3-20-3RV-10
oil filter Q2U-E250*10FS
flushing filter ZTJ300.00.07
BFP lube filter XW-630X40H
filter FAX (NX)-630*5
Filter element LS002-300-005T
regeneration device filter CZX-40*30
jacking oil pump oil-return filter T-X265A/20
oil filter Q3U-E100*5S
ion-exchange resin filter JCAJ043
