CS-III differential pressure transmitter by yoyik
Date:2020/2/5 16:13:51 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,The basic function of the differential pressure transmitter is that during the working process of the hydraulic system, the impurity particles in the oil are blocked by the filter element in the oil filter, so that the filter element is gradually blocked, resulting in the pressure difference at the inlet and outlet (i.e. pressure loss). When the differential pressure value reaches a certain value, the power supply is automatically connected to display the signal.
CS-III differential pressure transmitter is mainly used for pipeline oil filter. When the hydraulic system is working, the filter element in the oil filter is gradually blocked due to intercepting the contaminants in the system, and the pressure difference at the inlet and outlet produces a pressure difference. When the pressure difference increases to the set value of the transmitter, the transmitter automatically sends a signal to instruct the operator to clean or replace the filter element to ensure the safe operation of the system.
The connection thread of CS-III differential pressure transmitters is M22x1.5.
Model Working pressure(Mpa)
CM-I 32
CM-II 32
CMS-III 32
CS-IV 32
CS-V 32
CY-I 1.6
CY-II 1.6
YM-I 32
CYB-I 1.6
ZS-I -0.9
ZS-II -0.9
ZKF-II -0.9
DFSYC-2020-02-05-A
