Steam Turbine OPC Over-speed Protection System

Date:2016/7/12 19:34:45 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

China Steam Turbien Over-speed Protection System OPC Valve





PRODUCT DESCRIPTION



The OPC system is known as overspeed protection system. The steam turbine overspeed protection system is one of the important devices to protect the steam turbine from overspeed damage. It mainly protects the steam turbine by controlling the speed of the steam turbine and adjusting the load of the steam turbine. For steam turbine units, overspeed is one of the most dangerous situations, if not controlled, will cause a major damage to the unit.



Working principle of Steam Turbine OPC system:

The speed of the steam turbine is detected by speed sensors and speed controllers. When the overspeed protection system detects that the speed of the steam turbine exceeds the safe speed, it will send out a signal immediately, and the controller will activate the fuel cut-off valve and the speed limit valve to cut off the fuel supply of the steam turbine and control the load of the steam turbine to make the steam turbine stop safely.



Application of OPC Valve:

OPC valves are widely used in various types of steam turbines, compressor sets, pumping stations, etc. It can effectively protect the steam turbine from overspeed damage and avoid equipment failure and safety accidents caused by the overspeed of the steam turbine.





REGULAR SPARES



Overspeed Protection Solenoid Valve Z2804076

Overspeed Protection Solenoid Valve GS060600V

Overspeed Protection Solenoid Valve CCP115D

Overspeed Protection Solenoid Valve CCP115M

Overspeed Protection Solenoid Valve AM501-1-0149

Overspeed Protection Solenoid Valve CCP230M

Overspeed Protection Solenoid Valve CCP230D

Overspeed Protection Solenoid Valve 3D01A012

Overspeed Protection Solenoid Valve SV4-10V-C-0-00

Overspeed Protection Solenoid Valve 4659D78002

Overspeed Protection Solenoid Valve Z6206052






PRODUCT PICTURE



Turbine Overspeed protection



RELATED PRODUCTS



OPC Solenoid Valve Servo Valve AST Solenoid Valve CS-1 Rotational Speed Sensor
OPC Solenoid Valve Servo Valve AST Solenoid Valve CS-1 Rotational Speed Sensor





Please contact us if your need is not listed above. SEND EMAIL
