Heat Exapansion Sensor TD-2 use for power plant

Date:2019/10/16 11:25:56 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

Expansion temperature sensor is based on the principle of thermal expansion of liquid, solid and gas when heated. This kind of temperature sensor includes liquid expansion, solid expansion and gas expansion.

The turbine TD-2 thermal expansion sensor (0-35mm) is designed for measuring the absolute expansion displacement of steam turbine units in the steam turbine industry. It has two kinds of instructions: in-situ and remote transmission. In-situ indication has a large field of vision, it uses intermediate frequency displacement sensor as sensing element; remote indication has good linearity, strong anti-interference, simple structure, easy to damage, good reliability, long-term continuous use, output is constant current. It has been selected by domestic large and medium-sized steam turbine manufacturers, and can be used in other precise displacement measurement occasions.
