Appearance: Component A indicator    Yellow, uniform and free of impurities

                     Component B indicator     light yellow, uniform and free of impurities



Features and uses:

The tie rope (belt) of the large generator electric stator winding end is impregnated and the compliant polyester felt is impregnated before use.



Instructions:

When the ambient temperature is lower than 20 ° C, the component A of the room temperature curing adhesive 793 is subjected to baking treatment before use. Baking temperature 30 ° C ~ 40 ° C, holding time ≥ 4 hours.

The curing time of the room temperature curing adhesive 793 at an ambient temperature of not lower than 25 ° C should be not less than 24 hours. In order to achieve good electrical insulation properties, it is best to bake for 8 hours at 60 ° C ~ 80 ° C.



Precautions:

The RTV epoxy adhesive 793 should be used within 2 hours.



Storage environment:

Store in a cool dry place. The product has a shelf life of 12 months at room temperature from the date of manufacture. The product has passed the storage period and can only be used after passing the inspection.





Dongfang Yoyik Engineering Co., Ltd is located in Deyang, Sichuan, provides different kinds of industrial products and brands. Our company is specialized in researching and developing hear-resisting and wear-resisting materials. As a pump and valve manufacturer ourselves, we also offer other brands both domestic and from abroad.



Dongfang yoyik offer RTV epoxy adhesive 793
