Spot in stock servo valve G761-3033B supplied by Dongfang yoyik

Date:2019/6/10 16:51:44 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

Spot in stock servo valve G761-3033B supplied by Dongfang yoyik

The servo valve G761-3033B is used as a three-way and four-way throttle type flow control valve for better control performance when used with a four-way valve. This series of valves is a high performance two-stage electro-hydraulic servovalve rated at 4L/min to 63L/min at a rated pressure drop of 7Mpa. The pilot stage of the valve is a symmetrical two-nozzle flapper valve driven by a dry double air gap force motor; the output stage is a four-way spool valve. The spool position is mechanically fed back by a cantilever spring rod. The valve series is single, sturdy, reliable, and has a long service life. These valves are suitable for position, speed, force (or pressure) servo control systems with high dynamic response.

Features:

1. Adopting the new Servo Jet pilot stage to improve the dynamic characteristics of the whole valve;

2. The flow passage design of the large flow valve greatly increases the rated flow of the valve;

3. The position of the main spool is electrically feedback using a displacement sensor;

4. Built-in electronic amplifier performs closed-loop control on spool displacement;

5. Fail-Safe function to ensure that the machine is in a safe position in the event of an unexpected power failure;

6. Fast dynamic response, high control accuracy, long service life, etc.



We also supply:



stainless steel globe throttle check valve (welded) LJC40-1.6P

bellows relief valve BXF-40

safety valve 3.5A25

vacuum pump KZ/100WS

stainless steel globe throttle check valve (welded) LJC100-1.6P

mechanical trip valve F3DG5S2-062A-50-DFZK-V

safety valve 5.7A25

Shutoff valve F3RG03D330

Isolation valve F3DG5S2-062A-220AC-50-DFZK-V/B08

sealing oil differential pressure valve KC50P-97

mechanical seal A108-45

vacuum pump 30-WS

Oil-water alarm OWK-2

EH oil Circulating pump 02-125801-3

Shutoff valve HGPCV-02-B30

sealing oil vacuum oil tank float valve BYF-80
