Dongfang yoyik supply original servo valve 072-559A

Date:2018-7-16 16:36:36 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

Dongfang yoyik supply original servo valve 072-559A

The servo valve 072-559A is a well-known brand of the key components in the electro-hydraulic servo control developed. It is a hydraulic control valve that receives the analog electrical signal and outputs the flow and pressure of the corresponding output modulation.

 servo valve 072-559A

Processing customization

no

Type

Proportional valve

Material

cast iron

Model

072-559A

Brand

MOOG

Scope of application

widely

product name

Servo valve

Applicable medium

Oil

Applicable temperature

23（℃）

Nominal pressure

42（MPa）

Nominal path

4（mm）

Installation form

23

working temperature

Normal temperature

Type (channel position)

Straight through

Connection form

Thread

Parts and accessories

accessories

Flow direction

one-way

Driving mode

electromagnetism

Form

Plunger

Pressure environment

Atmospheric pressure

Main material

cast iron

 servo valve 072-559A



Electro-hydraulic servo valve has many advantages, such as fast dynamic response, high control precision and long service life. It has been widely used in the electro-hydraulic servo control system in the fields of aviation, space, ship, metallurgy, chemical industry and so on.



The typical servo valve consists of permanent magnet torque motor, nozzle, baffle, valve core, valve sleeve and control chamber. When the input coil enters the current servo valve, the gear plate moves to the right to increase the throttle effect of the right nozzle, reduce the flow rate, increase the right back pressure, reduce the throttle effect of the left nozzles, increase the flow rate, and decrease the left back pressure. The force at both ends of the spool is out of balance, and the spool moves to the left. The high pressure oil flows from S to C2 and sent to the load. The load return oil flows through the C1 to the oil tank and enters the fuel tank. The displacement of the valve core is proportional to the input current of the torque motor, and the fluid pressure acting on the valve core is balanced with the spring force, so the differential current of the torque motor is proportional to the displacement of the valve core in the balance state. If the input current is reversed, the flow will also be reversed.
