Dongfang yoyik supply Rotation Speed Sensor CS-2

Rotation Speed Sensor CS-2. The CS-2 type speed sensor is an active three wire sensor.

1.       sensors are identified with positive end input, negative terminal COM, power supply terminal (applicable to DC+12V ~ 24V).

2.       the rotating machinery needs to measure the positive speed with 1 CS-2 sensors; if you need to measure the reverse speed with 2 CS-2 sensors

3.       CS-2 sensor can measure positive rotation or reversal, two sensors can be interchangeable, the angle of the phase clip is 90 degrees, and the end face of the sensor is vertically measured.

Wheel surface, installation distance: between 1 and 1.5mm

4.       Gear material requirements: all kinds of magnetic and steel materials are acceptable.

Gear modulus: more than 1.5

5.       measuring objects: 1 slot, 3 teeth, 30~120 teeth (which can be customized by the user).

6.       sensor installation thread: M16 x 1

The length of the sensor's solenoid is L:60 to 200mm (which can be customized by the user).

7.       the sensor outlet lines are identified: (positive input, negative terminal COM, power supply terminal DC+12V) should be connected to the instrument terminal.



Rotation Speed Sensor CS-2 features:

1. Induction type iron metal object

2. Digital current sink output (Collector opening)

3. A better signal to noise ratio than a magnetoelectric sensor

4. Excellent low speed performance and high speed performance. The output signal from 0 to 100KHz is independent of speed.

5. Anti electromagnetic interference
