Dongfang yoyik supply high quality covering varnish 188

Date:2018-5-30 14:53:54 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

Dongfang yoyik supply high quality covering varnish 188

Product Name: covering varnish 188

Standard: Q/XB1196-1999

Composition, characteristics, performance and use:

covering varnish 188. Heat resistance grade F grade. The film is hard, fast drying, good adhesion and excellent electrical properties. It is suitable for coil coating of traction motor and coating of heat-resistant insulating parts.

covering varnish 188

covering varnish 188 performance requirement:

Serial number

Index name

unit

Index value

1

Viscosity 4# viscometer 23 + 2 centigrade

S

≥40

2

The solid content is 105 + 2 centigrade

%

-

3

Drying time of lacquer film

H

≤24（23±2℃）

4

Insulation liquid capacity of 105 + 2 C transformer oil 24h

—

-

5

fineness

µm

≤30

6

The diameter of the elastic core shaft is 3mm 180 + 2 C

—

≥1

7

Electrical strength

Normal

MV/m

≥60

After immersion 24h



-

Hot state



-

8

Volume resistivity

Normal

Ω.m

≥1.0×1012

fter immersion 24h

-

Hot state

-

covering varnish 188

covering varnish 188. It has good electrochemical, thermal, mechanical and chemical properties, mostly varnish and coloured paint. Insulating paint is a special kind of lacquer in lacquer. Insulating varnish is an important insulating material that can be solidified into insulating film or insulation under certain conditions based on polymer. Insulating varnish is composed of base material, flame retardant, curing agent, pigments and fillers, and solvents.

covering varnish 188

Requirement

1. excellent insulation performance

2. good adhesion and high mechanical strength;

3. the contractile stress is small;

4. the heat resistance should meet the different requirements of the transformer.

5., outdoor or special environment should meet its special requirements, such as radiation protection, corrosion protection, UV protection and so on.

6. the process is good, such as good operation, non-toxic or low toxicity, short drying time and so on.

covering varnish 188

The same series of products are:

epoxy air-dry varnish        1504

air-drying red insulating varnish      J1030

B-class fast-dry insulating varnish  1035

covering varnish       1230

epoxy filling adhesive       53101

air-dry red insulating varnish

insulating varnish    1032

alcohol acid coating varnish    1230

air-dry clear insulating varnish         H31-2

clear insulating varnish   H31-3

alcohol acid coating varnish    Y1230

clear insulating varnish   Y31-3

Semiconductor strip         9332 1*17*2200

covering varnish       188

RTV dipping varnish          792

RTV dipping varnish          793

Air-dry Polyester Red Insulating Varnish          J1348
