J0705 Room temperature curing Silicon steel sheets adhesiveDate:2018-1-31 11:29:36 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,
J0705 Room temperature curing Silicon steel sheets adhesive
Silicon steel sheets adhesive J0705 is a two-component curing adhesive. It is composed of low viscosity epoxy resin and curing agent.
Features and uses
Silicon steel sheets adhesive J0705 is suitable for brushing and bonding silicon steel sheets of generator stator core during lamination. It has strong adhesion, good physical, mechanical, electrical properties and heat resistance.
Before use, the two components shall be mixed evenly, and brushed on the stator core end face or between silicon steel sheets with a brush.
Appearance: uniform color, mechanical impurities.
Viscosity: ≤ 60 s
Shear strength: ≥ 17 MPa
Curing time: room temperature ≤ 24h
Insulation and heat resistance class F (temperature resistance 155C ) for generator
