 HY111 11130/HY-VT12L China made integrated vibration transmitter sensor


The integrated vibration transmitter HY111 11130/HY-VT12L is mainly composed of a vibration speed sensor and a transmitter module, combined into an integrated vibration transmitter. It can be used to monitor the vibration status of rotating machinery such as fans, water pumps, and coal mills. It converts the vibration speed value (or displacement value) into an output standard 4-20mA current signal and can be connected to PLC, DCS systems, etc.
The transmitter adopts a two wire connection method, making wiring simpler and more convenient. Integrated structure, sealed to IP65. Durable and resistant to high temperatures, impacts, and harsh environments. Multiple installation methods and vibration range can meet the application requirements of various occasions.
 HY111 11130/HY-VT12L China made integrated vibration transmitter sensor
2 Technical parameters:
1. Frequency response: 10-1000 Hz, 5-1000 Hz (optional)
2. Measurement range: 0-20mm/s
Displacement 0-1000um (optional)
Speed range 0-100mm/s (optional)
3. Output current: 4-20mA
4. Working voltage:+24VDC
5 measurement directions: vertical or horizontal (see label)
6. Operating environment: Temperature: -20 ~80 Relative humidity: ≤ 90%
7. Installation thread: M10 * 1.5 (or customized)
