JZ-7-3-204B Protection and automatic control devices intermediate relay

Date:2023/12/1 11:28:52 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

 JZ-7-3-204B Protection and automatic control devices intermediate relay

The JZ-7-3-204B intermediate relay is used in various protection and automatic control devices to increase the contact capacity of protection and control circuits.

main performance of JZ-7-3-204B intermediate relay
The wires used in conventional 100V and 220V electromagnetic intermediate relays are very thin and have a large number of turns, resulting in easy wire breakage, low reliability, and long action and return times. This series of intermediate relays uses a static electronic control circuit to control the simultaneous conduction or disconnection of multiple sealed inlets in the middle.
It has the following performance and characteristics:
Adopting high-performance sealed relays, moisture-proof, dustproof, continuous wiring, and high reliability.
Accurate action voltage, high return coefficient, no jitter, low power consumption, multiple contacts acting or returning simultaneously (controllability).
After the relay is activated, there is a light indicator and a power indicator.
The electrical and mechanical lifespan of 3 relays is long.
four
High insulation and voltage resistance level. The contact capacity is large, and the contact resistance is small.
Good anti-interference characteristics, suitable for places with strong interference or poor power supply voltage quality
 JZ-7-3-204B Protection and automatic control devices intermediate relay
