The  EH oil Diatomite filter element ZS. 1100B-002 is used for the regeneration unit of the turbine EH oil system to filter the water in the EH oil, deacidify, etc. When the acid value of cool oil phosphate increases by 0.03%, the diatomite filter element needs to be replaced.



When the oil enters the filter element, its impurities are blocked, and the clean oil is discharged from the filter outlet. The filter element has high concentricity, high pressure bearing and good straightness.



The fire resistant oil regeneration device in the power plant is composed of diatomite filter and cellulose filter. During the operation of the unit, the acid value of the fire resistant oil is easily exceeded due to long-term high temperature operation, water content in the oil, impurities and other reasons. This problem can control the rise time of acid value from the aspects of operation, maintenance and technical management. The EH oil Diatomite filter element ZS. 1100B-002 can be connected and put into operation when the system acid value is high, and its cost is also an economic and effective configuration of the system.
