Actuator Filter

Date:2016/7/12 16:55:10 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,

China Steam Turbine Actuator Filter Manufacturer





DESCRIPTION



Actuator is an important part of EH Oil system of steam turbine. It controls the valves through the differential pressure of high pressure oil. In order to ensure the performance and reliability of the system, the cleanliness of the oil in the actuator is very important.



The filter elements for Actuator is installed on the oil motive integrated block, and the oil is filtered before enter the servo valve to protect the valves. The mesh is 10μm, and needs to replace two times a year.





TECHNICAL SPECIFICATION OF ACTUATOR FILTER



1. End cover material: aluminum alloy/carbon steel galvanized/stainless steel/reinforced nylon
Support framework: carbon steel galvanized/stainless steel
3. Sealing material: Nitrile (NBR) rubber/fluororubber, with good oil resistance and sealing performance
4. Filter material: glass fiber/stainless steel woven mesh
5. Filtering accuracy: 1, 3, 5, 10, 15, 20, 25
6. Liquid flow direction: from outside to inside/from inside to outside
7. Brand: Yoyik



APPLICATION



The application range of turbine actuator filter elements is very wide, covering almost all industries, especially in the metallurgical industry, automotive industry, electrical equipment, chemical industry, engineering machinery, paper industry, shipbuilding industry, machine tool manufacturing, and other fields.





REGULAR MODELS



AP6E602-01D10V/-W DP2B01EA01V/-F DP3SH302EA01V/-F
AP1E102-01D01V/-F LQ01-2 AP1E102-01D10V/-W
DP6SH201EA10V/-W EH50A.02.03 DP6SH201EA01V/F
DP6SH201EA10V/W DP201EA03V/-W HP0501A10VNP01
DP301EA10V/-W AP1E101-01D03V/-WF AP6E602-01D01V/-F
DP2B01EA10V/-W DP201EA01V/-F DP301EA01V/-F
DP3SH302EA10V/W QTL-6021A ZTJ300-00-07
HY-10-001-HTCC LH0060D025BN/HC AP3E302-01D10V/-W
AP3E302-02D10V/-W HQ25.11Z DP302EA10V/-W





PRODUCT PICTURE





Actuator FiltersActuator FilterActuator Filter element
