The intelligent vibration monitoring and protection device JM-B-3ZD-300 is mainly suitable for power generation, steel, metallurgy, chemical and other fields. It continuously monitors and measures the bearing vibration (absolute vibration) and shaft vibration (relative vibration) of various rotating machinery, making it easy for users to analyze and maintain the machine's working conditions. Equipped with current output, it can be used for connecting external recorders and microcomputers.

This device is digitized, with good stability, high accuracy, simple operation, and easy maintenance. The friendly human-machine dialogue interface puts this product at the forefront of domestic technology.

Function

1. With high intelligence, parameter settings enable board operation

2. Suitable for long-term online monitoring, easy to install and debug, and on-site maintenance

3. Alarm switch output

4. Equipped with 420mA current analog output

5. Range, alarm, and danger values can be set arbitrarily

6. Real time signal output (TDM)

7. Automatic maximum value memory and query of sampled signals
