APF7.820108F-A China offers active power sampling board
Date:2026/5/19 10:43:29 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,APF7.820108F-A China offers active power sampling board
The sampling board APF7.820108F-A has the characteristics of fast response speed, strong filtering ability, flexible installation, and easy expansion, which can meet the needs of different users. The new active power APF adopts modular design, which improves the reliability of the whole machine. Its adjustment speed is fast and the operating range is wide. After adopting multiple and multi level PWM technology, the content of carrier frequency harmonics at the compensation point is greatly reduced. Each module of APF can compensate for reactive power and harmonics separately or simultaneously.
Characteristics of sampling board APF7.820.108F-A
Comparison between APF module and channel filtering technology
·APF module, single unit capacity 30~200A
Simple interface, convenient wiring, easy parallel connection
·Strong ability to suppress fluctuations and flicker, damping power grid oscillations
Low self harmonic, multi unit parallel connection, ripple self elimination technology
It can dynamically and real-time filter out harmonics of the 2nd to 50th order, with an effective filtering rate of up to 95%
Low self power consumption and small footprint
Independent air duct dust-proof design, maintenance free
·Multi functional and multi-mode operation mode
