20MG50.11.09.83J China offers coal mill support ring
Date:2026/5/15 14:27:00 Visits: Author:Dongfang YOYIK Engineering Co; Ltd,20MG50.11.09.83J China offers coal mill support ring
The oil seal support ring 20MG501.09.83J is made of Q235, precision forged, and undergoes quenching and tempering, high-frequency quenching, and low-temperature tempering heat treatment. Its hardness reaches HRC55-60, with high strength, good rigidity, deformation resistance, impact resistance, and long wear life; The material contains corrosion-resistant elements such as chromium and nickel, and the surface has been treated with blackening/galvanizing+passivation and rust prevention. It is resistant to coal powder corrosion, high temperature oxidation, and grease immersion, and is suitable for high temperature, high dust, and high humidity environments of coal mills.
2. Precision manufacturing process
Adopting CNC turning+precision grinding+flat grinding integrated molding, the flatness of the end face is ≤ 0.008mm, parallelism is ≤ 0.01mm, the coaxiality of the inner and outer circles is ≤ 0.01mm, and the dimensional tolerance is strictly controlled within ± 0.02mm; the surface roughness Ra is ≤ 0.8 μ m, smooth and free of burrs and sharp edges, avoiding scratching the oil seal lip; Circular structure design, rectangular cross-section, uniform thickness, sufficient rigidity, can uniformly withstand axial pressure of the oil seal, prevent local deformation and eccentric wear of the lip.
3. Core performance advantages
Rigid support, anti deformation and collapse: Made of high-strength materials and precision structure, it can stably support two oil seals, preventing lip deformation, collapse, and outward rotation under high pressure, high temperature, and vibration, ensuring a tight fit between the oil seal lip and the shaft surface, and reliable sealing.
Accurate positioning, anti eccentric wear and leakage: strict dimensional accuracy and coaxiality control ensure that the oil seal is concentric with the grinding roller shaft, avoiding lip eccentric wear, local overheating, early wear and leakage, greatly extending the service life of the oil seal (increasing by 30% to 50%).
Wear resistant and corrosion-resistant, long service life: high hardness surface+rust proof treatment, minimal friction and wear with oil seals and shaft surfaces for a long time, resistant to coal powder erosion, high temperature oxidation, and grease corrosion, with a service life of up to 15000-20000 hours, synchronized with the overhaul cycle of the coal mill.
High temperature resistance and compatibility with working conditions: Long term temperature resistance of -40 ℃ to+180 ℃, with no strength attenuation, dimensional stability, deformation, or brittle cracking at high temperatures, suitable for high temperature environments in the grinding roller bearing chamber.
