TSF-400X10 is a coarse filter element designed specifically for the oil suction circuit of hydraulic systems. It belongs to the TSF series of oil suction filter accessories and is core compatible with water tank top suction filters and various industrial hydraulic oil tank suction ports. It undertakes the key responsibility of oil pump pre protection and is widely used in industrial fields such as machinery, mining machinery, large hydraulic stations, metallurgical equipment, etc. By intercepting larger impurities in the oil, it avoids internal component wear, jamming or damage caused by oil pump suction pollutants, ensuring stable hydraulic system circulation from the source. It is the core compatible component for oil suction filtration of industrial hydraulic equipment.



This filter element meets the oil suction flow requirements of medium to large hydraulic systems, balancing coarse filtration protection and oil suction smoothness. It can efficiently intercept mechanical impurities such as metal debris, dust, sand and gravel, and will not cause problems such as oil pump suction and air pockets due to excessive filtration resistance. It is suitable for the core function positioning of "pre coarse filtration and ensuring flow" of oil suction filters. The filter material is made of high-quality stainless steel woven mesh, which has the advantages of strong corrosion resistance, stable filtration efficiency, and repeatable cleaning and use. It is made by precision weaving technology, with uniform pore size, and can accurately control the filtration accuracy. At the same time, with excellent structural strength, it can resist oil impact and impurity friction, avoid damage to the filter material causing impurity leakage, and extend the service life of the filter element.



The TSF-400X10 filter element meets the core requirements of oil suction conditions and adopts a cylindrical structure design, which can perfectly adapt to the installation structure of the TSF series top suction filter. It is firmly fixed through dedicated connectors, easy to install and disassemble, and does not require complex tools, greatly reducing operation and maintenance costs. The filter cartridge frame is made of high-strength carbon steel or stainless steel punched plates, which have strong rigidity and outstanding deformation resistance. It can adapt to low-pressure working conditions of the oil suction circuit, and the rated pressure resistance level meets the standards of hydraulic oil suction systems. Even under the impact of oil fluctuations, it can maintain structural stability and avoid deformation of the frame affecting the filtration effect. At the same time, the optimized flow channel design further reduces the resistance of oil passing through, improves oil efficiency, matches the nominal flow rate of 400L/min, and controls the pressure difference loss within a reasonable range to ensure stable oil suction performance of the oil pump.



This filter element has broad adaptability and universality to various working conditions, with a working temperature range of -30 ℃ to 110 ℃. It can adapt to cold and high temperature industrial production environments and has good compatibility with commonly used working media such as hydraulic oil and emulsion. It will not undergo chemical reactions that may cause filter material failure or oil pollution. Its stainless steel filter material can be repeatedly cleaned and reused. After high-pressure flushing to remove surface impurities, it can be put back into use, further reducing consumable costs and meeting the low-cost operation and maintenance needs of industrial equipment. In addition, the filter element can be directly adapted to similar specifications of oil suction filters, and some models can replace imported similar products with strong adaptability. It can be used as a matching filter element for new equipment or as a replacement part for existing equipment. With precise specification adaptation, stable filtering performance, and convenient operation and maintenance characteristics, TSF-400X10 filter element has become the preferred accessory for oil suction protection in medium and large hydraulic systems, providing reliable guarantee for oil pumps and subsequent hydraulic components, helping to improve equipment operation stability and reduce the risk of failure shutdown.
