Axial piston pump 25MCY14-1B is a high-performance hydraulic power component widely used in hydraulic transmission systems of machine tools, forging, metallurgy, engineering, and mining machinery. Its core design adopts an axial plunger structure with oil distribution plate and cylinder body rotation, which achieves oil suction and discharge through the reciprocating motion of the plunger in the cylinder body. It has the characteristics of compact structure, high output pressure, and stable flow rate, and is an indispensable key component in modern hydraulic systems.



Compared with traditional pumps, this pump has the advantages of simple structure, small volume, and light weight, making it easy to install and maintain. At the same time, it has strong self-priming ability and can work stably under lower inlet pressure, adapting to various working conditions.



The rated pressure of 5MCY14-1B can reach 31.5MPa, and the displacement range covers multiple specifications (such as 25mL/r), suitable for medium and high pressure hydraulic systems. Its high-efficiency and energy-saving characteristics reduce the operating costs of the system, while the low-noise design improves the working environment. In addition, the pump has bidirectional variable function, which can change the flow rate by adjusting the angle of the inclined plate, and achieve multiple control modes such as constant pressure and constant power, meeting the control requirements of complex systems.



In terms of application scenarios, this pump is commonly used as a power source for hydraulic presses, main pumps for excavators, and hydraulic control systems for metallurgical equipment. For example, in forging machinery, it provides a stable high-pressure oil flow to ensure high-precision machining of the equipment; In mining machinery, its high reliability and durability adapt to harsh working conditions. It is worth mentioning that the pump only needs to replace the motor oil distribution plate to be used as a hydraulic motor, achieving multiple uses for one machine and further improving its economy
